Specification：
Basic Parameter
L X W X H ：210 MM x 130 MM x 60 MM
Screen：Resolution 640 X 480 5.7’ TFT Color LCD
Weight： 2 Kg (Including Battery)
Interfaces：LEMO-6 LEMO-15 DB-25
Lithium: 12V 3000mAH
Power Supply： 110V/60hz 220V/50hz
Operating Temperature： -20° ～ 50°Ｃ
System Parameter
CPU： ARM11 Embedded 32位 500M Processor
Operating System：liunx 2.6
RAM：256M
SD CARD memory capacity： 8G
USB interface：12M/S, USB-2.0（Host/Slave）
Encoder：1024 Pulse/Round Resolution:0.1mm
Operation Language：English/Chinese
LCD Luminance：1-8 Grade
Inspection Parameter
Independent Detection Frequency: 2 in total
Frequency Range：10 Hz～10 MHz，Step 1 Hz
Gain：0 dB～99 dB，Step 0.1 dB
Phase：0～359°，Step 1 Deg
Intelligent Mixing Unit：1 in total
Probe Driver：Vpp=1～8V
Probe Impedance：50Ω 100Ω
X&Y Gain Control: Y/X = 0.1—10
Calibration Curve：Amplitude Phase Equivalent
Display Mode：Impedance, time base, rectangular coordinates, polar coordinates Scanning
Speed：1-100 Grade
Center coordinates: X Y adjustable
Digital Signal
Digital Filtering：HPF（0Hz～2000Hz）、LPF（10Hz～10000Hz）
Filtering Points：1-1024
Broadband： 100Hz～10MHz
A/D Velocity：16bit 100M
Min-Senstivity: 1mV
Real-Time Average：2 4 8 16 32
Automatic Balance：Digital Electronic Balance
Alarm Set
Type: Phase/Non-continuous Windows and Door Frame
Gate：A/B
Amplitude Value：10%-120%
Sound：On/Off
Peripheral：Photoelectric I/O
Parameter Storage
Detection Save,Delete,Edit：above 10000 sets
Real-time signal preservation,playback,analysis,save and print： 8G/24Hour
Testing Pics： Above 10000 PCS
USB Storage: Available
Print： Online/Wireless
Help System
Automatically display date,time and battery capacity
Easy operation,real-time screen point-out
Online hotkey,graphics,words help
